Mainly used for washing and concentrating in various domestic and overseas waste recycled pulp, chemical pulp before or after bleaching. Removing ink particles, fillers and other small impurities from the slurry with high efficient.
Application&Feature
1.Mainly used for washing and concentrating in carious domestic and overseas waste recycled pulp,chemical pulp before or after bleaching,Removing ink particles, fillers and other small impurities from the slurry with high efficient.
2.High efficiency of impurity prolapse, high efficiency dewatering ,very clean after wash the slurry.
3.Less occupied area, large production capacity, low power consumption,
Main Specification
| Type | ZNG10 | ZNG15 | ZNG20 | ZNG25 | |
| Working Width(mm) | 1000 | 1500 | 2000 | 2500 | |
| Concentration Of Input Pulp(%) | 0.8-1.5 | ||||
| Concentration Of Output Pulp(%) | 8-15 | ||||
| Production Capacity(t/d) | MOW(t/d)(AOCC37#) | 40-70 | 55-100 | 70-130 | 100-180 |
| ONP(t/d) | 30-50 | 40-70 | 50-90 | 60-120 | |
| Ash Removal(%) | ≧90 | ||||
| Power Of Main Motor(kw) | 30 | 37 | 55 | 75 | |
| Motor For Screw Conveyor | 5.5 | 5.5 | 7.5 | 7.5 | |
