Mainly used for removing heavy impurities in the pulp like gravel, scrap iron, dust and large ink particles.
Application&Feature
1.Mainly used for removing heavy impurities in the pulp like gravel, scrap iron, dust and large ink particles.
2.Divided Design, the cleaners can be dicided into 3-4parts, which make it easier for disassembly, assembly and replace.
3.Different deslagging ways: open and closed type impurity discharge to meet different working environment.
4.The bottom of cone adopts wear-resistant ceramics. It ensures the stable deslagging and long service life.
Main Specification
| Type | KH-400 | KH-600 | KH-800 | KH-1000 | LH-1500 |
| Rate Passing Capacity Of Single Equipment(L/min) | 400 | 600 | 800 | 1000 | 1500 |
| Inlet Consistency(%) | 0.3-1 | 0.3-1.2 | 0.4-1.2 | 0.4-1.5 | 0.4-1.5 |
| Pressure Of Inflow Pulp(mpa) | 0.2-0.4 | 0.2-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 |
| Diameter Of Deslagging Out let(mm) | 4-10 | 6-12 | 6-14 | 6-18 | 6-18 |
